AT3817A

LCR Meter

The newly designed AT3817A features a true-color TFT-LCD display with a full Chinese operation interface (configurable to English). Large font display for more intuitive readings.

AT3817A adopts continuous frequency points from 10Hz to 100kHz with a resolution of 0.001Hz. Test signal level: 0.01Vrms~2.00Vrms, 100.0μA-20.00mA, pure DC signal source DCR measurement and internal DC bias ±2.5V, with optional external bias

AT3817A can test 4 parameters of components simultaneously, each parameter can be freely configured, achieving full 6-digit display for all four primary and secondary parameters. It can scan 10 frequencies or level lists, and allows calibration of 3 user-defined frequencies for improved accuracy.

Built-in 14-bin comparator for automatic component sorting via HANDLER interface combined with PLC.

The instrument comes standard with RS232, RS485, and USB interfaces, supports SCPI and Modbus protocols, and can be optionally equipped with a GPIB interface.
